General Information:
|
|
| Indoor/Outdoor Unit |
TAC-09CHSD/TPH11IT |
| Operation Type |
Reverse Cycle |
|
|
Noise (Sound Power Level):
|
|
| Indoor Unit – dB (A) |
47 |
| Outdoor Unit – dB (A) |
58 |
|
|
Rated Values:
|
|
| Cooling Capacity (KW) |
2.6 (1.0~4.0) |
| Heating Capacity (KW) |
4.05 (1.0~4.8) |
| Rated Input-Cooling (KW) |
0.595 |
| Rated Input-Heating (KW) |
0.985 |
| Moisture Removal (Litre/Hour) |
0.8 |
| AEER |
4.34 |
| ACOP |
4.06 |
| Energy Star Rating for Cooling (Hot & Humid) |
9.5 |
| Energy Star Rating for Cooling (Mixed) |
5.5 |
| Energy Star Rating for Cooling (Cold) |
6 |
| Energy Star Rating for Heating (Hot & Humid) |
3.5 |
| Energy Star Rating for Heating (Mixed) |
2.5 |
| Energy Star Rating for Heating (Cold) |
2 |
|
|
Electrical Data:
|
|
| Power Supply |
220-240V~50Hz |
| Rated Current Cooling (A) |
4.3 |
| Rated Current Heating (A) |
4.6 |
| Max Current (Cooling / Heating) (A) |
6.6/7.4 |
| Max Input (Cooling / Heating) (W) |
1450/1580 |
| Standby Power (W) |
4 |
| Outdoor Operating Temperature Range (°C) |
-15°C~52°C |
| Indoor Operating Temperature Range (°C) |
16°C~31°C |
| Breaker Size (A) |
16 |
Fan System:
|
|
| Air Circulation (m3/H) Cooling |
620 |
|
Air Circulation (m3/H) Heating |
620 |
|
Indoor Fan Speed H/M/L (rpm) Cooling |
1150/780/600 |
|
Indoor Fan Speed H/M/L (rpm) Heating |
1220/920/800 |
|
Indoor Fan Speed H/M/L (rpm) Dry |
750 |
|
Indoor Fan Speed H/M/L (rpm) Sleep |
750 |
| Indoor Fan Motor Output (W) |
25 |
| Outdoor Fan Speed (rpm) |
1000 |
| Outdoor Fan Motor Output (W) |
33 |
|
|
Refrigerating System:
|
|
| Compressor Type |
Inverter |
| Refrigerant (type/gram) |
R32 / 620g |
Piping:
|
|
| Liquid Pipe (mm) |
Ø 6 |
| Gas Pipe (mm) |
Ø 9.52 (3/8″) |
| Maximum Piping Length (m) |
15 |
| Max Height Difference (m) |
5 |
|
|
Dimensions / Weight:
|
|
| Product Dimensions-Indoor (W x D x H) |
820 x 306 x 195mm |
| Product Dimensions-Outdoor (W x D x H) |
795 x 305 x 549mm |
| Net Weight-Indoor (kg) |
10 |
| Net Weight-Outdoor (kg) |
22 |
| Carton Dimensions-Indoor (W x D x H) |
890×380×265mm |
| Carton Dimensions-Outdoor (W x D x H) |
835×340×585mm |
| Gross Weight with Packaging-Indoor (kg) |
12 |
| Gross Weight with Packaging-Outdoor without pipe (kg) |
24 |
